Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | 6020158 |
| Body Style | Cylindrical |
| Connection Type | M8 3-Pin |
| Current Consumption | ≤ 10 mA (without load) |
| Diameter | 5 mm |
| Dropout Voltage | ≤ 2 V (With Ia = 200 mA) |
| Frequency, Switching | 5 kHz |
| Housing Material | Stainless Steel, V2A, 304 |
| IP Rating | IP67 |
| Length, Housing | 38 mm |
| Measurement Range | 0.8 mm |
| Mounting Type | Flush |
| Output | NPN-NO |
| Primary Type | Inductive Proximity Sensors |
| Sensing Range | ≤ 0.8 mm |
| Series | |
| Shielding | Shielded |
| Size, Thread | M5 x 0.5 |
| Supply Voltage | 10-30 VDC |
| Thread Length | 22 mm |
| Thread Size | M5 x 0.5 |
| Type | Inductive |
